Products / LOCKS / MORTISE LOCKS / TER MODULAR

TER MODULAR – Modular handle lock, WITHOUT notch
M4001
Latch/lever 1/2 cylinder 1/2 handle in mechanism
TER MODULAR – Modular handle lock, WITHOUT notch
M4007
Latch 1/2 handle in mechanism
TER MODULAR – Modular handle lock, WITHOUT notch
M4011
Latch/lever bolt and 1/2 handle in mechanism
TER MODULAR – Modular handle lock, WITHOUT notch
M4001
Latch/lever 1/2 cylinder 1/2 handle in mechanism

GENERAL CHARACTERISTICS

  • Pressure installation (recommended to glue to the glass)
  • Handles made of AISI 316 stainless steel
  • Stainless steel A2 screws
  • Decorative covers made of AISI 316 stainless steel
  • Euro-profile multipoint security cylinder
  • Glass tightening seals made of cork rubber material
  • Reversible latch operated by key, latch throw 10 mm
  • Lever with two key turns and anti-cut treatment, lever throw 20 mm
  • Cylinder entry 40 mm
  • Certified according to UNE-EN 1935:2002/AC:2004, Grade 7 / 200,000 cycles
  • Certified according to UNE-EN 1670:2007/AC:2008, Grade 5, highest corrosion resistance



Standard manufacturing

  • Finishes: Polished stainless steel – Satin stainless steel
  • Glass thickness 10 mm



Options available on request

  • Electrolytic finishes
  • RAL colours
  • (/T) Stop on the mechanism for locks with outward opening for installation with strike plate WITHOUT electric opener
  • (/TE) Stop on the mechanism for locks with outward opening for installation WITH electric opener strike plate (recommended to avoid sabotage)
  • (/SCU) Stop on the bracket for locks with outward opening (recommended to avoid sabotage)
  • The desired stop can be ordered by adding (/T), (/TE), or (/SCU) after the lock reference selected
  • Glass thicknesses up to 17.52 mm

Additional Information

  • Locks for EXTERIOR opening installed with electric strike plates (trunk type) must have a STOP
  • Locks installed with electric strike plates (trunk type) can only open in the direction of the mechanism’s position
  • Strike plates (trunk type) with stops are only for locks with INTERIOR opening
  • Strike plates correspond in all cases to the same position as the trunk locks

Technical information
